Description
Power your Ultra 5/7 series monitor using a Gold mount battery with this Micro Battery Plate from SmallHD. The battery plate mounts directly onto your monitor using included captive mounting screws, and it provides power to the monitor from a separately available standard or micro-sized Gold mount battery.

The battery plate also features two D-Tap outputs that provide 11 to 17 VDC of power for additional accessories. The ports have a 5.8V digital E-fuse that is resettable, providing current protection that will shut the ports down if they are overloaded, without affecting the monitor power.

SmallHD Micro Power Plate Specs
Power
Power Output
D-Tap: 11 to 17 VDC at 5.8 A
General
Inputs/Outputs
2 x D-Tap
Plate Front / Battery Mount
Gold Mount
Plate Rear Mount
Proprietary Battery Plate
Number of Battery Bays
1
