Manfrotto Gimbal 460 Kit

SKU: MVG460
Regular price $1,621.60

The Gimbal 460 has an independent lock on each axis to make pre-balancing your camera quick and simple. You can unlock and balance one axis at a time, and this feature also allows the gimbal to be stored away easier. The Gimbal 460 runs for up to 12 hours on included batteries, which are rechargeable using a supplied charger.

The quick release system uses two mounting plates. There's a built-in platform and a removable top plate, both with an Arca-Swiss standard design. The top plate can be used to switch your camera between the gimbal and tripods or other supports with Arca-Swiss compatibility, and you won't have to rebalance the gimbal when mounting the camera back on.

Select cameras can also be connected to the gimbal via the included cables for a more seamless workflow between the camera and gimbal. You'll be able to adjust certain camera settings directly from the gimbal. The Gimbal 460 offers lock, pan, follow, and all follow modes and provides 360° pan, 230° tilt, and 360° roll rotation.

Key Features

  • 10 lb payload
  • Touchscreen display with direct access to most gimbal modes and settings
  • iOS/Android companion app
  • Arca-Swiss standard platform and quick release plate
  • Independent lock on each axis for easy balancing
  • Up to 12-hour battery life
  • 360° pan, 230° tilt, and 360° roll rotation

Modes

  • Lock mode: the orientation of the camera is fixed
  • Pan mode: the roll and tilt axes are fixed, and the camera only moves left and right
  • Follow mode: the roll axis is fixed, and the camera moves left/right or up/down
  • All follow mode: the camera moves according to the user's hand motions
Specifications
Load Capacity 0.33 to 10 lb / 0.15 to 4.54 kg
Number of Axes 3-Axis (Pitch, Roll, Yaw)
Rotation Range Yaw (Pan): 360°
Pitch (Tilt): 230°
Roll: 360°
Connectivity
Inputs/Outputs 2 x Unspecified USB
Battery
Battery Runtime 12 Hours
General
Materials Aluminum
Mounting 1 x 1/4"-20 Male
1 x 1/4"-20 Female
Dimensions 16.93 x 9.45 x 6.89" / 43 x 24 x 17.5 cm
13.78 x 7.91 x 2.8" / 35 x 20.1 x 7.1 cm
Weight 3.66 lb / 1.66 kg (without Battery)
