Fxlion BM-HV300 28.8V 293Wh B-Mount Lithium-Ion Battery for ARRI ALEXA 35 (10,200mAh)
This Fast Charger features four channels. With 4 Amps charging current, your batteries can be charged within a short time simultaneously.
The B-Mount battery is a new design, developed by ARRI and Bebob. The idea is to create a new future-proof industry standard. There are a lot of advantages in contrast to V- and Gold-Mount batteries. We put some together for you:
Through additional data pins, the camera or luminaire can communicate with the B-Mount battery. It can read for example status of cycles or battery capacity. Different battery plates, designed for 14.8 or 28V can communicate with the battery. This way, the battery can adjust its voltage to the according plate and so the used device. This is convenient when using bi-voltage batteries.
Due to the internal release mechanism, the battery plates get even smaller than with V- or Gold-Mount plates. This is also a big advantage, as cameras get smaller. The mounting mechanism is built really rugged so the battery doesn’t move while on a camera.
B-Mount batteries come in different designs and with different power specifications. But the minimum power output is specified at 15 amps at 24V.
We also provide two new chargers, suitable for B-Mount batteries.
Capacity: 10.2Ah/293Wh
Voltage: 28.8V
Load: 10A / 250W (max.)
D-Tap Outputs: Yes (2x) 16V 60W (max.)
USB-A Output: 5V/2A 10W (max.)
USB-C In- / Output: 5V~20V/3A 60W(max.)
Dimensions: 154mm x 100mm x 87mm (LxWxH)
