Cube 625 is the latest in Teradek’s line of professional, scalable integrated decoders designed for video over IP delivery. Compatible with Cube encoders, Cube 625 offers SD/HD MPEG-4 AVC decoding for point-to-point video distribution, allowing content creators, broadcasters and system integrators to cost-effectively and reliably meet strict QoS requirements.

With flexible HDMI/3G-SDI dual-output and Ethernet/WiFi (2.4/5Ghz)/cellular USB connection options, Cube 625 streamlines IP video deployment in existing workflows and enhances infrastructure for all users. Small form factor and high-performance decoding make it one of the most versatile solutions for content delivery strategies in the video ecosystem.

Specifications:

Video

• Video Inputs
  • HDMI 1.4a: Full Size
  • SD/HD/3G-SDI (75 Ω BNC)

Supported Input Resolutions

• Supported Resolutions:

• • 1080p 23.98/24/25/29.97/30/50/59.94/60*
  • 1080i 50/59.94/60
  • 1080PsF 23/24/25/29/30
  • 720p 50/59.94/60
  • 576i
  • 480i
  • 480p (for HDMI output only)
  • 576p (for HDMI output only)

 Video Processing

• Video Compression: Decompresses H.264, Baseline, Main and High Profile
• Supported Video Bitrate: 250 Kbps to 15 Mbps:*15 Mbps (wired), 10 Mbps (WiFi)
• Test Pattern Generator Support: None
• Video Format Conversion Support: Built in Video Scaler and Deinterlacer
• Color Correction: None

Protocol Support

• Network Protocols: TCP/IP, UDP, HTTP, DHCP, NTP, SSL, IGMP
• Supported Video Transport Protocols:
  • RTP/RTSP: Unicast/TCP, Unicast/UDP, Multicast/UDP streams
  • MPEG Transport Stream: Unicast/TCP (pushed in from an external source, or pulled down from a remote server such as Core), Unicast/UDP, Multicast/UDP
  • Teradek Streaming : Unicast/UDP, Multicast/UDP
• Remote Control: Teradek Core

Audio Processing

• Audio Compression: AAC-LC, MPEG Layer 2

Inputs

• Audio Input: Embedded Audio Input
• Analog Line or Mic in, adjustable gain

Outputs

• Audio Output: Headphone output

Physical

• Dimensions: 120.7 x 76.2 x 27.9mm (4.75"W x 3"D x 1.1"H)
• Weight: 328.9g
• Construction: Milled Aluminium
• Mount-ability
  • Can be mounted horizontally or vertically with
  • 1/4" 20 mounting holes

Interfaces

• Http: WebUI for Configuration and Control
• Configuration Interfaces:
  • OLED Display with joystick Navigation buttons
  • Feature-rich WebUI for configuration and control
• Switches: On/Off and Reset Switch
• Mobile App: Vuer, Live:Air
• Usb Interface Functionality: Powered USB 2.0 host port

Network

• Ethernet: 10/100/1000 BASE-T Gigabit
• Wireless: None
• Usb: USB 3G/4G Modem support**** refer to this article on which modems are known to be supported: https://support.teradek.com/hc/en-us/articles/217447037-What-3G-4G-USB-Modems-are-supported-
• Rf Channel Selection: None
• Encryption: None

Power

• Power Input: 2 Pin Connector Power input
• Battery: No Battery Included
• Nominal Power Consumption: 7W (no WiFi)
• Auxiliary Power Input: 6-28V DC
  Real-Time H.264 (AVC) Decoder
  Ethernet and USB Interfaces (No WiFi)
  HDMI and SDI Video Outputs
  Camera Top Form Factor
  Built-In Scaler
  OLED Display
  Powers by AC Adapter or 2-pin Connector
  Outfitted for 1/4" Mounting
