Sennheiser XSW-D PEDALBOARD RX - Pedalboard Receiver for XSW-D Digital Wireless System
- One touch pairing
- 2.4 GHz digital transmission for worldwide operation
- 75 m range (250 ft) in optimal conditions
- Up to 5 hours battery life on a single charge
- Automatic frequency and interference management
- Switch between multiple transmitters linked to one receiver
- Mute from either transmitter or receiver
XSW-D receiver with 6.3mm (1/4”) and male XLR outputs
The Sennheiser XS Wireless Digital Pedalboard Receiver operates at a range of up to 250' (75 m) and can last up to five hours on its built-in battery. It can be muted from either the transmitter or the receiver.
The Sennheiser XS Wireless Digital Pedalboard Receiver is a digital wireless receiver that is designed to work with a pedalboard.
When you pair the Sennheiser XS Wireless Digital Pedalboard Receiver with a transmitter, the device will work between 2.400-2.483.5 GHz. Up to five Sennheiser XS Wireless Digital Pedalboard Receiver and transmitter systems can be used simultaneously thanks to Sennheiser's automatic frequency and interference management technology.
| Charging time | typ. 3 h |
| Cell type | Li-Ion |
| Nominal voltage | 3.7 V |
| Cell capacity | 850 mAh |
| Operating time | up to 5 h |
| Codec | aptX Live |
| 3.5 mm Jack/XLR | 80 - 18,000 Hz |
| 6.3 mm Jack | 10 - 18,000 Hz |
| Audio output max. | 12 dBu |
| Signal-to-noise ratio | 106 dB |
| THD | < 0.1 % |
| Audio latency | < 4 ms |
| XSW-D XLR FEMALE TX | approx. 102 x 24 x 28 mm |
| Frequency range | 2,400 - 2,483.5MHz |
| Transmission power | (EIRP) max. 10 mW |
| Modulation | GFSK with TDMA |
