Powerful camera receiver with a lightweight aluminum housing and for evolution wireless G4 100P Series systems. For documentary, Mobile Journalism and audio for video applications.

Frequency range
A: 516 - 558 MHz
A1: 470 - 516 MHz
AS: 520 - 558 MHz
B: 626 - 668 MHz
C: 734 - 776 MHz
D: 780 - 822 MHz
E: 823 - 865 MHz
G: 566 - 608 MHz
GB: 606 - 648 MHz
JB: 806 - 810 MHz
K+: 925 - 937,5 MHz

Dimensions
Approx. 82 x 64 x 24 mm

Compander
Sennheiser HDX

THD, total harmonic distortion
≤ 0.9 %

Weight
(incl. batteries) approx. 160 g

Audio output
3.5 mm jack socket: +12 dBu (mono, unbalanced)

Signal-to-noise ratio
≥ 110 dBA

Switching bandwidth
up to 42 MHz

Peak deviation
±48 kHz

Nominal deviation
±24 kHz

Operating time
Typically 8 h

Modulation
Wideband FM

Power supply
2 AA batteries, 1.5 V or BA 2015 accupack

Current consumption
at nominal voltage: typ. 180 mA
with receiver switched off: ≤ 25 µA

Adjacent channel rejection
≥ 65 dB

Intermodulation attenuation
≥ 65 dB

Powering
3 V battery / 2.4 V rechargeable battery

Receiving frequency
Max. 1680 receiving frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels

RF sensitivity
< 1.6 μV for 52 dBA eff S/N

Squelch
low: 5 dBµV, middle: 15 dBµV, high: 25 dBμV

Temperature Range
-10 °C to +55 °C

Receiver Principle
Adaptive diversity

Blocking
≥ 70 dB

Sennheiser EK 100 G4--B
