Pelican 1535 Air Carry-On Case

Pelican 1535 Air Carry-On Case - Ultra-Lightweight Armor for Elite Imaging Kits

The Pelican 1535 Air Carry-On Case is a premium, high-durability protective transit solution designed to safeguard sensitive camera packages, lenses, and production electronics while adhering strictly to maximum airline overhead dimensions.

Built for the Demands of Modern Production

For traveling filmmakers and photojournalists, transporting a complete high-end cinema kit involves navigating strict airline constraints while ensuring uncompromised protection for sensitive components. Modern production packages—comprising cinema cameras that record massive RAW bitrates, lenses designed for maximum sensor coverage, and critical monitoring gear—require a robust transit framework. The Pelican 1535 Air Carry-On Case solves the logistical burden of heavy transport by utilizing a proprietary HPX² polymer formulation. This material delivers a weight reduction of up to 40% compared to standard protective enclosures, maximizing your allowable travel payload capacity and ensuring you can bring your primary camera bodies, high-speed storage media, and high-fidelity production optics straight into the cabin.

Field production conditions are rarely ideal, exposing equipment to severe environmental risks ranging from dust-choked desert shoots to unpredictable marine settings. The Pelican 1535 Air features an advanced watertight EPDM O-ring seal and tough Press and Pull™ latches that maintain a pressurized barrier against moisture and fine particulates. To handle rapid changes in altitude and climate during transit, the integrated automatic purge valve utilizes a hi-flow Gore-Tex 3-micron hydrophobic non-woven membrane. This system balances internal and external air pressure seamlessly, mitigating the risk of structural vacuum locking while offering environmental thermal management that shields calibrated, color-accurate production monitors and imaging systems capturing wide dynamic range from rapid temperature fluctuations.

Mobility across rugged sets is enhanced via quiet-rolling, stainless-steel bearing wheels and a robust, retractable extension trolley handle. The dual-layered padlock holes feature stainless steel protectors to prevent theft during transit or on-set staging. Designed precisely to fit maximum airline carry-on regulations, the case ensures that equipment responsible for capturing high dynamic range imagery and elite production values remains securely in your possession from pre-production through wrap.

Key Technical Specifications

• Material Construction: Proprietary super-light HPX²™ Polymer (up to 40% lighter than standard polymer formulations)

• Interior Dimensions (L × W × D): 20.39" x 11.20" x 7.21" (51.79 x 28.45 x 18.31 cm)

• Exterior Dimensions (L × W × D): 21.96" x 13.97" x 8.98" (55.78 x 35.48 x 22.81 cm)

• Lid Depth: 2.00" (5.08 cm)

• Bottom Depth: 5.21" (13.23 cm)

• Total Internal Volume: 0.95 ft³ (0.03 m³)

• Weight (Empty): 8.69 lbs (3.94 kg)

• Weight (With Foam): 9.98 lbs (4.53 kg)

• Maximum Buoyancy: 64.80 lbs (29.39 kg)

• Latch System: Dual Press and Pull™ ABS Latches

• Sealing: Waterproof EPDM O-ring gasket seal

• Pressure Equalization: Automatic Purge Valve with Hi-Flow Gore-Tex 3-Micron Hydrophobic Non-Woven Vent

• Mobility: Retractable extension trolley handle and quiet-rolling stainless-steel bearing wheels

• Security: Stainless steel padlock hole protectors (Padlock hole diameter: 0.31" / 0.79 cm)

• Certifications: IP67 (Dustproof/Waterproof Immersion) & MIL-SPEC certified

• Temperature Operational Range: Minimum: 0°F (-18°C) | Maximum: 140°F (60°C)

Production FAQ

Question: How do the exterior dimensions comply with international airline carry-on regulations?

Answer: The Pelican 1535 Air features a form factor engineered precisely to meet maximum airline carry-on dimensions at 21.96 x 13.97 x 8.98 inches, allowing you to keep critical gear overhead on most major commercial flights.

Question: How does the pressure equalization valve protect lenses during high-altitude transport?

Answer: The Pelican 1535 Air features an automatic purge valve with a hydrophobic Gore-Tex membrane that balances internal air pressure continuously during flight while blocking moisture and dust from entering the interior chamber.

Question: How does the payload capacity handle heavy cinema camera rigs and dense production hardware?

Answer: The Pelican 1535 Air features a high structural buoyancy rating of 64.80 lbs and crushproof HPX² polymer walls, allowing it to easily support heavy, high-density gear packages without compromising shell integrity.

Question: How does the thermal management protect sensitive electronic storage and media drives in extreme climates?

Answer: The Pelican 1535 Air features an IP67-rated EPDM O-ring seal and robust polymer walls that insulate internal gear across an operational temperature range of 0°F (-18°C) to 140°F (60°C).
